3100 Protektor Acrylic Conformal Coating

Price 400.0 INR/ Unit

Get a Price/Quote

MOQ : 20 Pieces

3100 Protektor Acrylic Conformal Coating Specification

Feature
Disposable

Application Method
Spray, Brush, Etc

Color
Clear

State
Liquid

Fragrance
Solvent Based

3100 Protektor Acrylic Conformal Coating Trade Information

Minimum Order Quantity
20 Pieces

FOB Port
Nhava Shiva

Payment Terms
Cash in Advance (CID), Cash Advance (CA)

Supply Ability
10000 Pieces Per Month

Delivery Time
-5 Days

Sample Available
Yes

Sample Policy
If order is confirmed we will reimburse the sample cost

Main Export Market(s)
Australia, Central America, Asia, North America, South America, Eastern Europe, Western Europe

Main Domestic Market
All India

Certifications
IPC-CC-830C RoHS CDoT ISO 9001:2015

3100 Protektor Acrylic Conformal Coating About

Protektor Conformal Coating is a fast-drying, single-component acrylic (resin) conformal coating for PCBs and electronic assemblies a protective coating that shields printed circuit boards from moisture, corrosion, dust, fungus, caustic vapours, thermal shock, dielectric stress and chemical attack. A trusted PCB coating / PCB conformal coating for electronics, telecom, automotive, defence and aerospace manufacturing.

Its high dielectric strength prevents high-voltage arcing and the corona effect, while the protective film insulates and protects the electrical and electronic components. It conforms to IPC-CC-830B / Military-Grade MIL-I-46058C, is approved by the Centre for Development of Telematics (C-DOT), and is RoHS compliant and environment friendly.

New to conformal coatings? Read our Complete Guide to Conformal Coating for PCBs the six coating types, silicone vs acrylic, how to choose, application, drying times and IPC-CC-830 standards.

Also available: the UV-traceable variant (glows under UV for inspection) and our Protektor PCB Cleaner for surface prep before coating.

Product Details

Type	Acrylic Resin (AR)
Appearance / Clarity	Clear transparent
Specific Gravity	0.95
Propellant	Non-CFC, flammable
Temperature Resistance	-70C to 120C
Dry-to-Touch Time	30 minutes
Film Thickness	26 micron
Shelf Life	18 months
Grade	MIL-I-46058C / IPC-CC-830B
Packing	550 ml aerosol spray 5 L carboy (brushable coating)

Electrical Properties

Insulation Resistance (after chamber test)	2.5 10¹¹ Ohms
Breakdown Voltage	700 V at 26 micron

Advantages

Fast drying (dry-to-touch in ~30 minutes)
Single-component spray for printed circuit board assemblies
Protects from humidity, fungus & corrosion by forming a film on components
Provides insulation against high-voltage arcing
Excellent flexibility & solderability
Convenient aerosol application, efficient for assembly-line operations

Fields of Application

Telecom equipment & telephone exchanges
Computer & process-control equipment, PLCs, variable frequency drives
Electronic instruments (weighing scales, multimeters)
LED/CFL lighting
Mobiles, computers, laptops, tablets, hard-drive PCBs
Automotive control units & defence/aerospace electronics

Cured film can be easily removed using Protektor Conformal Coating Thinner. As a conformal coating manufacturer in India since 1989, Micron Aerosols supplies Protektor in 550 ml aerosol and 5 L bulk, with OEM / private-label manufacturing for electronics and defence production lines.

The information provided is correct to the best of our knowledge at the date of publication and is intended as guidance for safe handling, use, storage and disposal not as a warranty or quality specification.
